Tenders Description & Specification for Automatic Trainer Compact PLC 40 Inputs Outputs
Automatic Trainer Compact PLC 40 Inputs Outputs
Standard modular unit hanging box, PLC embedded installation.
Input and output of the PLC module All the terminals are led out to the panel through the adapter terminal, and connected using the K2 test line.
PLC module selects Siemens CPU1215C DC/DC/DC, SM1223, CM1241 module and CM1234 module, provides 30 digital input, 10 transistor (DC24V) output, 16 relay output, 6 analog input, 4 channels Analog input, support for memory cards, support for Ethernet module expansion.
The PLC input can simulate the digital input state through the switch operation.
LED lights indicate the input and output status.
Performance parameters
Input power: single-phase three-wire system 220V±10% 50Hz
Dimensions: 297mm × 310mm × 80mm
Machine capacity: <1KVA
Weight: <100kg
Working conditions: ambient temperature -10 ° C ~ +40 ° C Relative humidity <85% (25 ° C)
Product composition
CPU1215c module digital input
Module analog input
module analog input
Total power supply
Module relay output
PLC module
module analog output
PLC DC 24V output
Ltekonline are the manufacturers of Automatic Trainer Compact PLC 40 Inputs Outputs used to demonstrate engineering principles in Engineering Colleges, Engineering Schools and PLC Trainer Kits for Engineering Teaching Lab in Universities
