This product is designed with regulated power supply, AC low voltage current, frequency generator, buzzer, multi-socket, voltage regulator, etc., which provides abundant resources for measurement, debugging and new product development of electronic products.

This product integrates digital circuit and analog circuit training system, which can carry out analog circuit related test and digital circuit test.

Features:

Through the use of a variety of electronic components and assembly tools, not only can exercise students' assembly and debugging capabilities, but also can exercise students' curriculum design, graduation design, skill competition and other secondary development capabilities.

The equipment adopts a special plug, which is convenient for students to quickly set up the experimental circuit to complete the test.

Technical Parameters:

Machine capacity: <2KVA

Input power: three-phase five-wire system 380V±10% 60Hz

Working conditions: ambient temperature -10 ° C ~ +40 ° C Relative humidity <85% (25 ° C)

Dimensions: 1300mm × 650mm × 1500mm

Weight: <250kg.
