The cooling tower body of the experimental platform is a columnar structure made of transparent and observable acrylic material. The filler adopts the form of sparse distribution to compare and observe different layouts. The intermediate cooling plane is the surface of the filler. The cooling capacity of the filler.

The air enters the cylinder from the bottom and flows upward; the inlet section and outlet section are connected with a differential pressure gauge to measure the pressure loss.

Features:

The import and export data of the cooling tower can be digitally displayed by instruments;

The data of each point of the workbench cycle can be displayed on the PC through a USB device;

Cooling tower type 2 can be connected and compared with other types of cooling towers.
