Didactic Device For Studying Flow Measurements
Didactic device for studying flow measurements to study different flow measurement methods based on a Venturi, a diaphragm and a float flowmeter.
Supplied with a complete instructional manual with practical work (TP).
The bench is used to apply the steady-state energy conservation equation (Bernoulli’s equation).
The depress metric organs are transparent so that students can visualize the flow of the fluid inside.
This teaching equipment makes it possible to carry out the following practical exercises:
Direct comparison of the flow measurements made by a Venturi, a diaphragm and a rotameter.
Comparison of the pressure drops at the passage of each flow measurement device
Comparison of pressure drops through a sudden enlargement and a 90 ° elbow
Application of Bernoulli’s theorem for an incompressible fluid.
Supplied with a complete instructional manual with practical work (TP).
Specifications:
The bench must allow the following pedagogical operations:
Comparison of the pressure drops at the passage of each flow measurement device
Comparison of pressure drops through a sudden enlargement and a 90 ° elbow
Application of Bernoulli’s theorem for an incompressible fluid.
Direct comparison of the flow measurements made by a Venturi, a diaphragm and a rotameter.
Technical specifications:
A transparent rotameter graduated from 0 to 210 mm and supplied with a calibration curve from 0 to 35 l / min
nine pressure taps connected to a multi manometer graduated from 0 to 380 mm
A flow control valve
A sharp transparent enlargement (from 26 to 51 mm)
A transparent diaphragm with a diameter of 20 mm
The maximum flow will be 28 l / min
A transparent Venturi
Converging (dia 26 mm, 16 mm)
Collar (16 mm dia)
Diverging (dia 16 to 26 mm).
Ltekonline are the manufacturers of Didactic Device For Studying Flow Measurements used to demonstrate engineering principles in Engineering Colleges, Engineering Schools and Fluid Mechanics Teaching Equipment for Engineering Teaching Lab in Universities
