Axial fans are used to transport gases. The medium to be transported is drawn in axially to the drive shaft of the axial fan by the rotation of the rotor. The medium flows through the rotor and is discharged axially behind the rotor.

The experimental unit is fitted with sensors for pressure and temperature. The flow rate is determinate via differential pressure measurement on the intake nozzle. The microprocessor-based measuring technique is well protected in the housing. The measured values are transmitted directly to a PC via USB where they can be analyzed using the software included.

The experimental unit provides the basic experiments to get to know the operating behavior and the important characteristic variables of axial fans.

Features an axial fan with variable speed via an integrated controller, an intake pipe and a delivery pipe. The transparent intake and delivery pipes are fitted with guide plates for flow guidance. A flow straightener in the intake pipe serves to calm the air. This enables precise measurements even with heavily reduced operation. The air flow is adjusted by a throttle valve at the end of the delivery pipe.

All the advantages of software-supported experiments with operation and evaluation are offered by the software and the microprocessor.

Specification:

Transparent intake and delivery pipes

Throttle valve to adjust the air flow in the delivery pipe

Determination of flow rate via intake nozzle

Functioning and operating behavior of an axial fan

Axial fan with electronically commutated drive motor

Variable speed via integrated controller

Display and evaluation of the measured values as well as operation of the unit via software

Display of differential pressure, flow rate, speed, electrical power consumption and hydraulical power output, temperature and efficiency.

Due to integrated microprocessor-based instrumentation no additional devices with error-prone wiring are required.

Software with control functions and data acquisition via USB under Windows 8.1, 10.

Technical Data:

Intake pipe

Inner diameter: 110mm

Length: 275mm

Axial fan

Power consumption: 90W

Nominal speed: 9500min-1

Volumetric flow rate: approx. 600m3/h

Pressure difference: approx. 700Pa

Delivery pipe

Inner diameter: 110mm

Length: 310mm

Measuring ranges

Differential pressure: 0…1800Pa

Flow rate: 0…1000m3/h

Temperature: 0…100°C

Speed: 0…9999min-1

Power consumption: 0…500W

230V, 50Hz, 1 phase

230V, 60Hz, 1 phase; 120V, 60Hz, 1 phase

Dimensions and weight

LxWxH: 670x340x370mm

Weight: approx. 15kg.
