With security experiment terminals, pick up the conversion, convenient method may meet for Y shape or form of accidents. Have the security, easy operation does not damage easily motor characteristics of the terminal.

Motor base (2.5 mm thick plate, black plastic spraying), appearance beautiful and easy. The bottom four only install shockproof pads.

Technical Parameters:

Three-phase asynchronous motor starting

With the speed: Y-enables delta

Rated current IN = 0.83 A

Insulation level: grade E

Shell protection level: IP44

The rated speed: 1400 r/min

The power rating: PN = 0.25 KW

The rated voltage: UN = 380 V

Rated frequency: FN = frequency 50 Hz

Extreme number: 4 very

Voltage lasted 1 m not occur breakdown

Cos Φ = 0.7 (no-load)

Clearance and creepage distance: 3.0 mm frequency

Normal motor insulation resistance: 500 M Ω

Electrical strength: hot state or temperature rise test, electromotor winding and between cabinet put 1760 V.
