The training sets include a variety of types of thyristor typical application circuit units, through the related experiments, can be familiar with thyristor electrical characteristics, to master the control principle and control mode, raises the student the corresponding knowledge and skills.

Features:

Training bench with aluminum column frame structure, the power supply built-in integrated installation, safe and convenient to use, is not easy to damage.

Unit circuit hanging box configuration are complete, combination use, complete variety of critiquing the training content.

It can be set for an experiment subjects related units hang flexible increase or decrease in the box, in order to meet different user requirements.

Training platform has a good safety protection system.

Character Parameters:

Whole capacity: <2.0KVA

Input power: three phase, five wire, 380V±10% 50Hz

Work condition:

Environment temperature: -10ºC~+40ºC

Relative humidity: <85%(25ºC)

Dimension:1600mm×800mm×1800mm

Weight: <100kg.
