Tenders Description & Specification for Tool and Cutter Grinding Machine
Tool and Cutter Grinding Machine
Construction:
Wheel Head: It is of rigid construction and holds the spindle assembly. It can be fitted horizontally and swiveled vertically full 360 degree, for quick setting of compound angles. Wheel head is mounted on the rigid column, which can be raised/lowered up/down. Wheel head also can be adjusted 150 mm on cross direction.
Wheel Head Spindle:
Alloy steel hardened and ground spindle is mounted on precision preloaded radial ball bearings, which are greased packed. The grinding wheels can be mounted on both sides of the spindle and the wheels mount design is such that the spindle can be reversed.
Work Table:
This is mounted on the carriage and can be swiveled 45 degrees on either side of the column. This table has a smoother and rapid movement longitudinally on the carriage through a roller chain guided and supported in jibs. Slow movement is through a reduction gearbox. Change over from rapid to slow movement is through a push/pull knob. The precise movement on roller chain enables smooth, sensitive and accurate longitudinal movement even with heavy jobs. The adjustable reversing dogs on the work table are spring loaded for shockproof reversal of table.
Auxiliary Table:
This table is mounted on work table and in both horizontal and vertical planes. It can hold job up to 600 mm with the aid of raising blocks. It’s spindle nose has ISO 50/MT 5 tapers and the spindle is mounted to taper roller bearings.
| Specifications | Unit | |||
| Max. swing on std. center | mm | 250 | 250 | 280 |
| Swing with raising blocks | mm | 350 | 350 | 380 |
| Length between work head and RH tail stock | mm | 330 | 520 | 610 |
| Admit between centers | mm | 440 | 670 | 760 |
| Max. Height center of wheel above table | mm | 300 | 300 | 380 |
| Longitudinal traverse | mm | 400 | 480 | 510 |
| Cross traverse | mm | 200 | 250 | 250 |
| Swivel either side of centre(End scale) | deg. | – | 9 | 9 |
| Swivel LH/RH of column (Center scale) | deg. | 45°/45° | 45°/45° | 45°/45° |
| Size of table | mm | 750 x 115 | 920 x 140 | 1010 x 140 |
| Vertical adjustment of wheel head | mm | 210 | 210 | 290 |
| Wheel Head Swivel | deg. | 3600 | 3600 | 3600 |
| Tilting in either direction | deg. | 180 ± | 180 ± | 180 ± |
| Spindle speed | rpm | 3800/5600 | 3800/5600 | 3800/5600 |
| Motor power | KW/HP | 0.75/1 | 0.75/1 | 0.75/1 |
| Net weight of the machine | kg. | 750 | 1150 | 1250 |
| Gross weight of the machine | kg. | 900 | 1350 | 1450 |
| Dimension of Machine (L x W x H) | mm | 1075 x 1100 x 1400 | 1325 x 1170 x 1460 | 1325 x 1170 x 1460 |
Ltekonline are the manufacturers of Tool and Cutter Grinding Machine used to demonstrate engineering principles in Engineering Colleges, Engineering Schools and Workshop Machines for Engineering Teaching Lab in Universities
