Tenders Description & Specification for Blood Gas Serum Electrolyte Analyzer For Electrolyte Measurement
Blood Gas Serum Electrolyte Analyzer For Electrolyte Measurement
Technical Specification:
Measuring time: ≤25~90s(Type A~Type I, Time for sampling, measuring, washing and printing)
Sample size: 60~300μl(Type A~Type I, optional)
Applicable specimens: blood serum, blood plasma, whole blood, cerebrospinal fluid and dilute urine
Data storage: 1000
Automatic sampling: No
Display: LCD
Operating mode: YES/NO button
Print: intemal graphic thermal printer
Barcode scanning: No
CPU: 16bit
Working condition: Temperature: 5°C~35°C Relative humidity ≤80%
Power: AC220V±20;50Hz±1Hz
Weight: 12kg
Technical characteristics for the Electrolyte Analyzer:
The machine adopts innovative international patent technology such as wave theory flushing method and direct flushing pipe method to avoid block and crossed contamination.
Every time putting the specimen into the machine, the machine could simultaneously detect eight ions including K,Na,Cl,iCa,nCa,TCa,pH,Li,TCO2,AG as well as ten parameters.
It can absorb the specimen and calibrate the ion automatically, and make analysis quickly. It only takes 25s to finish the process of absorbing the specimen to indicating the result.
After conducting analysis to specimens, the equipment will automatically flush, keeping the electrode standby in clean status.
It has a ultra large screen with completely English display, which is quite clear for operators . The built-in printer can print out the result , so it's very quick and convenient.
The equipment is capable of storing 1000 result, and it can be extended to be more than 10000.The equipment will automatically refresh once it reaches the store limit.
The equipment is set with quality control correction procedure, and capable of correcting measured data automatically, as well as by the two parameters of pith and average deviation.
There are only two press button(i.e YES and NO)on the equipment while the menu is completely in English. Once there is a failure, the equipment will automatically prompt and remove it. It is really convenient.
The whole running process of the equipment is controlled by a computer. Also, automatic electric potential tracking and correcting software are adopted to ensure its stable performance.
Ltekonline are the manufacturers of Blood Gas Serum Electrolyte Analyzer For Electrolyte Measurement used to demonstrate engineering principles in Engineering Colleges, Engineering Schools and Electrolyte Analyzer for Engineering Teaching Lab in Universities
