training adopts aluminum frame type structure, the control object and actuators integrated installation, practical circuit and device adopts security terminal adapter, each unit with flexible, easy to use, not easy to damage.
the experimental circuit and devices are fully configured and can be used in combination to complete the training contents of a variety of subjects.
the training platform has a good security system.
performance parameters
input power: 230V plus or minus 10% 50Hz
external dimensions: 600mm x 500mm x 1000mm
unit capacity: < 1KVA
weight: < 60kg
working conditions: temperature - 10 ℃ ~ + 40 ℃ relative humidity < 85% (25 ℃)
product composition
control system
The control system adopts Siemens PLC, and the number of digital 10 is 10, and the analog quantity is 2 in 1.
control objects
Using transparent acrylic water tank, the liquid level change can be observed with liquid level sensor and flow sensor.
power supply configuration
single phase three-wire power supply input, through leakage circuit breaker control output, with emergency stop control button, press the emergency stop button breaker to cut off the power.
equipped with power indicator, European power output socket and secure type power supply terminal.
built-in ac power, with short circuit protection.
built-in dc power, with short circuit protection.
supporting devices
2 piece cylinders transparent water tank
1 piece transparent storage tank
three piece solenoid valves
1 piece water pump
flow sensor 1 piece
liquid level sensor 3 piece
water level switch 3 piece
PLC module 1 piece
1 set of programming software (teaching edition)
pipe fittings and joint sets
Complete training contents
Liquid level control experiment
Flow control experiment
Double capacity tank control experiment
Comprehensive control experiment of dynamic liquid level flow
PLC programming control experiment

Ltekonline are the manufacturers of Electrical Skills Bench Level Control used to demonstrate engineering principles in Engineering Colleges, Engineering Schools and PLC Trainer Kits for Engineering Teaching Lab in Universities
