Methods of Flow Measurement Apparatus
Methods of Flow Measurement Apparatus
Product Code: LTEKCTLB-FMT61-00121

Tenders Description & Specification for Methods of Flow Measurement Apparatus

Methods of Flow Measurement Apparatus

Learning Objectives / Experiments:
Flow measurement with
Orifice plate flow meter and measuring nozzle
Comparison of different instruments for flow measurement
Determining the corresponding flow coefficients
Pressure measurement with pitot tube
Calibrating measuring instruments
Venturi nozzle
Rotameter.

Specification:
6 tube manometers to determine the pressure distribution in venturi nozzle, orifice plate flow meter and measuring nozzle
Measurement of the total pressure with pitot tube
Different methods of flow rate measurement
Measuring instruments: orifice plate flow meter/measuring nozzle, venturi nozzle and rotameter
Water supply via laboratory supply
Flow rate determined by base module.

Technical Data:
Venturi nozzle: A=84…338mm²
Orifice plate flow meter: diameter=14mm
Measuring nozzle: diameter=18,5mm
Rotameter: max. 1700L/h
Angle at the inlet: 10,5°
Angle at the outlet: 4°
6 tube manometers: 390mmWC
Dimensions and Weight
LxWxH: 1100x672x900mm
Weight: approx. 30kg.

Ltekonline are the manufacturers of Methods of Flow Measurement Apparatus used to demonstrate engineering principles in Engineering Colleges, Engineering Schools and Fluid Mechanics Teaching Equipment for Engineering Teaching Lab in Universities
