Tenders Description & Specification for Plate Rolling Machine
Plate Rolling Machine
3 Roll PYRAMID Type outline with twofold pre-squeezing game plan
Top roll is repaired and base moves and down.
Base moves up-down through water powered chambers.
Two base rolls are force driven via planetary apparatus box with electric powered engine.
Twisting rolls are made of combination steel.
Dropper end assurance by pressure driven barrels.
Over-burden prevention
Assembled – in cone bowing connection.
Pre-Bending Capacity
|
Bending Capacity |
Bending Length |
Top-Roll Diameter |
Side-Roll Diameter |
Min o in Pre-Bending |
Min o in Bending |
Motor Power |
|
|
6 |
8 |
1500 |
185 |
165 |
278 |
555 |
5.5 |
|
8 |
10 |
1500 |
205 |
185 |
308 |
615 |
7.5 |
|
10 |
13 |
1500 |
20 |
200 |
330 |
660 |
7.5 |
|
6 |
8 |
2000 |
205 |
185 |
308 |
615 |
7.5 |
|
8 |
10 |
2000 |
220 |
200 |
330 |
660 |
7.5 |
|
10 |
13 |
2000 |
235 |
215 |
353 |
705 |
7.5 |
|
12 |
15 |
2000 |
265 |
245 |
398 |
795 |
11 |
|
15 |
18 |
2000 |
290 |
270 |
435 |
870 |
15 |
|
18 |
22 |
2000 |
320 |
290 |
480 |
960 |
18.5 |
|
20 |
25 |
2000 |
345 |
315 |
518 |
1035 |
18.5 |
|
25 |
30 |
2000 |
370 |
340 |
555 |
1110 |
22 |
|
30 |
35 |
2000 |
410 |
380 |
615 |
1230 |
30 |
|
35 |
40 |
2000 |
450 |
420 |
675 |
1350 |
30+7.5 |
|
40 |
50 |
2000 |
470 |
450 |
705 |
1410 |
37+7.5 |
Ltekonline are the manufacturers of Plate Rolling Machine used to demonstrate engineering principles in Engineering Colleges, Engineering Schools and Workshop Machines for Engineering Teaching Lab in Universities
