Tenders Description & Specification for Wood Working Spindle Moulder
Wood Working Spindle Moulder
Magnetic 2-step safety switch to prevent unintentional start-up is equipped with an extra-large easy access stop panel and a lock-out key to prevent unauthorized use.
Extra large, heavy cast-iron table with a smooth, ground surface finish.
Two (2) spindle speeds, with reverse.
Independent left and right fences feature precision micro-adjustment.
Industrial motor protected against dust by a totally enclosed cabinet.
Fence system / cutter head guard includes a cutter guard, spring hold-downs and a built-in 4″ dust collection outlet.
| Deluxe adjustment system | 27” x 25” (686 x 635 mm) |
| Table height | 34” (864 mm) |
| Spindle opening diameters | 7”, 3 1/2”, 3” (177, 89 & 76 mm) |
| Spindles diameters | 1/2” & 3/4” (13 & 19 mm) |
| Spindle travel | 3” (76 mm) |
| Spindle speeds | 8000 & 10 000 rpm |
| Fence sizes (aluminum) | 3” x 11” (76 x 279 mm) |
| Dust chute outlet | 4” (102 mm) |
| Overall dimensions (l x w x h) | 21 1/4” x 17 1/4” x 42 1/2″ (540 x 438 x 1080 mm) |
| Motor | 3 HP, 220 V, 1 Ph |
| Weight (shipping / net) | 343 lbs (156 kg) / 326 lbs (148 kg) |
Ltekonline are the manufacturers of Wood Working Spindle Moulder used to demonstrate engineering principles in Engineering Colleges, Engineering Schools and Workshop Machines for Engineering Teaching Lab in Universities
