Three Way Mixing Valve Training Panel
Three Way Mixing Valve Training Panel
Product Code: LTEKCTLB-TTE60-00110

Tenders Description & Specification for Three Way Mixing Valve Training Panel

Three Way Mixing Valve Training Panel

Learning Objectives / Experiments
Effect of mixing ratio on feed flow or circulating flow temperature
Effect of mixer setting on the flow rate
Function and operating behaviour of a three-way mixing valve
In conjunction with other training panels, it is possible to set-up a complete heating System.

Specification:
Trainer on heating systems and plumbing
3-way mixing valve
Circulating pump
4 rotameters
2 water connections for boiler
1 differential pressure overflow valve
4 bimetallic dial thermometers
2 heating water connections
Water connections made using quick-release couplings.

Technical Data:
Measuring ranges – flow rate: 3x 150…1700L/h, 1x 40…400L/h – temperature: 0…100°C
Pump – power consumption: 70W – max. flow rate: 60L/min – max. head: 4m
Three-way mixing valve – setting angle: 90° – opening time: 100s
Required for Operation 230V, 50/60Hz, 1 phase
Hot water supply: 1800L/h, cold water connection, Drain
Dimensions and Weight LxWxH: 1650x700x1850mm
Weight: approx. 112kg.

Ltekonline are the manufacturers of Three Way Mixing Valve Training Panel used to demonstrate engineering principles in Engineering Colleges, Engineering Schools and Thermal Training Equipment for Engineering Teaching Lab in Universities
