Venturi Meter Setup
Venturi Meter Setup
Product Code: LTEKCTLB-FMT61-0029

Tenders Description & Specification for Venturi Meter Setup

Venturi Meter Setup

Experiment purpose
To understand Venturi meter and orifice plate flowmeter experiment set and principle.
Draw pressure difference and flow relationship curve, confirm Venturi meter and orifice plate flowmeter discharge coefficient μ value.

Experiment principle
Venturi meter is widely applied in normal flowmeter in industrial tube, it contains three parts: contraction section, venturi, diffuser. Due to water section constriction, lead to contraction section front and back section pressure difference, and generate bigger potential energy difference, venturi active cross-section water flow energy increase, potential energy decrease, this potential energy difference can be calculated by differential pressure gauge.
Orifice plate flowmeter principle is the same as Venturi meter, according to energy equation and barometric surface principle will get the head loss Venturi meter(orifice plate flowmeter) flow equation Regardless of the head loss:
For Venturi meter:
For orifice plate flowmeter:
According to experiment equipment conditioner, the tube real measured value can be measured by volumetric method or by electronics flow meter.

Ltekonline are the manufacturers of Venturi Meter Setup used to demonstrate engineering principles in Engineering Colleges, Engineering Schools and Fluid Mechanics Teaching Equipment for Engineering Teaching Lab in Universities

Categories: Fluid Mechanics Teaching Equipment

Tags: Venturi Meter Setup
