This training device includes various types of motor, capacitor, inductor, capacitor and other modules. Through related experiments, you can familiarize with and control the principles and control methods of motor control, and cultivate students' corresponding knowledge and skills. Assessment of teaching and skills training in secondary vocational schools and technical schools.
Features
The training device adopts an aluminum column frame structure, and the power supply is integrated and installed.
The unit circuit hanging box is fully configured and can be used in combination to complete the training content of various courses.
The relevant units can be flexibly added to or deleted from the experimental subjects to meet the needs of different users.
The device has a good safety protection system.
Performance parameters
Input power: three-phase five-wire AC208V ± 10% 60Hz
Overall dimensions: 2000mm × 840mm × 1410mm
Overall capacity: 5KVA
Weight: <390kg
Working conditions:
Ambient temperature -10 ℃ ～ + 40 ℃
Relative humidity ＜ 85% (25 ℃)
Product composition
Power control screen
The power control screen uses an aluminum alloy profile panel, a closed box structure, and is connected to the lower rack as a whole. The upper part is fixed with an aluminum alloy beam that suspends the mobile box.
Power Box
The three-phase five-wire power input is controlled by the leakage circuit breaker and is equipped with an emergency stop control button. In an emergency, the emergency stop button is pressed to cut off the power supply.
Equipped with power indicator, power output socket and safety power output terminal.
Built-in AC208V and AC120V AC power supply, DC power supply, all power supplies have short-circuit protection function.
Main supporting experimental hanging boxes and devices
3 contactor boxes
1 thermal relay box
1 brake
1 button hanging box
1 phase failure relay box
1 time relay box
1 inductive sensor
1 capacitive sensor
1 heat sink
1 inverter box
1 soft starter box
Programmable controller (PLC, 24Vcc, 12 digital inputs, 8 digital outputs) Hanging box 1
1 ammeter hanging box
1 box for voltage distributor
One emergency module (placed in the power supply box)
Three-pole circuit breaker module
Bipolar circuit breaker module
Single-pole circuit breaker module
Tuner motor
Signing / activation module
Symbol / reversing module for 3 positions
Temperature regulator module
Limit (close) the sensor module
Limit (close) the sensor module
Including auxiliary contactor module
Multimeter
1 three-phase squirrel cage AC asynchronous motor
30 pieces of 4mm safety electrical connection cable

Ltekonline are the manufacturers of Industrial Control Training Bench used to demonstrate engineering principles in Engineering Colleges, Engineering Schools and PLC Trainer Kits for Engineering Teaching Lab in Universities
