The training platform adopts an aluminum column frame structure. The bottom of the training platform is equipped with universal wheels, which can be flexibly moved. Various modules are placed on the panel, which is easy to use and not easily damaged.
The communication module is complete and can be used in combination in various ways.
The overall structure is open and removable, which can easily replace modules. The module content is determined according to the principles of productive functions and integrated learning functions, so that the required modules can be conveniently selected during teaching or competition.
The training and assessment device is a low-voltage component, which is safe to use.
Performance parameters
Input power: three-phase four-wire AC380V ± 10% 50Hz
Overall dimensions: 1800X1760X700mm
Machine capacity: <1.5KVA
Weight: <120kg
Working conditions: ambient temperature -10 ℃ ～ + 40 ℃ relative humidity ＜ 85% (25 ℃)
Safety protection: with leakage voltage and leakage current protection devices, safety meets national standards
Product composition
Training table
The training table is supported by aluminum profile columns, and the universal wheels at the bottom are equipped with brakes, which can be flexibly moved and positioned. The table top adopts a 25mm thick high-density substrate, and the surface is treated with high-temperature and high-pressure fire-resistant board. It is equipped with one three-section drawer type drawer and one bottom cabinet. The structure is firm and beautiful.
Training workbench
Total power supply-4P earth leakage circuit breaker
Emergency stop unit
AC380V three-phase AC output unit + three-phase indicator + three-phase overload insurance
AC220V single-phase AC output unit + indicator + overload insurance
Socket
DC 24V power supply
Analog voltage DC0-10V signal and analog current DC4-20mA signal unit
Analog voltage DC0-10V signal and analog current DC4-20mA signal unit
DC 24V power supply
Socket
Panel module
plc master station (CPU 1211C + CM1241 RS232 + CM1243-2)
Layout drawing
plc slave (CPU 1211C + CM1241 RS232)
data decoupling module + AS-i slave (4DI)
Master station terminal module
Switch
Router
Slave terminal module
Button indicator module
Touch screen module
Button indicator module
Supporting devices
3 network cables
RS232 communication line
Wired USB network card
25 pieces of 4mm safety electrical cable
1 piece of digital multimeter
Software CD(not licensed software, teaching purpose with unlimit users)
can complete the training content
Siemens PLC programming training
Training of PLC and PLC Ethernet communication
Computer monitoring PLC status training
PLC and PLC232 communication training
Touch screen programming
PLC and touch screen communication training
Training of wireless communication between PlC and computer LAN
communication training of PLC

Ltekonline are the manufacturers of Network Communication Training Electronic Work Table used to demonstrate engineering principles in Engineering Colleges, Engineering Schools and PLC Trainer Kits for Engineering Teaching Lab in Universities
